The world of networking is on the move. Even small offices are shifting from Gigabit connections to the lightning-fast realm of 2.5 Gigabit connectivity. With CRS310-8G+2S+IN, we aim to give you the tools to outpace your competition with a strong combination of eight 2.5 Gigabit Ethernet ports and two 10 Gigabit SFP+ ports in a compact, powerful package! Furthermore, these SFP+ cages support multiple data rates: 1G, 2.5G, and 10G. So you can use this switch as a 10x 2.5G switch, if needed. Classic MikroTik flexibility!
The amazing Marvell 98DX226S switch-chip and integrated dual-core ARM CPU can handle the full potential of RouterOS v7. Run VLANs, Jumbo frames, link aggregation, ACL rules, and so much more! You can even do some hardware offloaded Layer-3 routing.
There are multiple mounting options. You can easily install the CRS310-8G+2S+IN in a standard 19” rack using the provided rackmount ears. Another option is to get the RMK-2/10 accessory set, which allows you to mount two CRS310 units within the same 1U 19” rack space or mount it in a 10” rack. The choice is yours!
General
| Unit Calculated Weight | 1.42 kg |
| Unit Calculated Volume | 0.006253 cubm |
| Units per Shipping Box | 6 |
| Summary | Mikrotik CRS310-8G+2S+IN: L3 Smart Switch. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. DC input voltage: 18 - 57 V. Rack mounting, Form factor: 1U |
| Unit Box Height | 0.245 |
| Unit Box Length | 0.37 |
| Unit Box Width | 0.06 |
| Model name | CRS310-8G+2S+IN |
Management features
| Switch layer | L3 |
| Switch type | Managed |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| SFP+ module slots quantity | 2 |
| USB Type-A ports quantity | 1 |
Network
| 10G support | Yes |
Design
| Form factor | 1U |
| International Protection (IP) code | IP20 |
| Number of fans | 1 fan(s) |
| Product colour | White |
| Rack mounting | Yes |
Performance
| Built-in processor | Yes |
| Flash memory | 32 MB |
| Internal memory | 256 MB |
| Mean time between failures (MTBF) | 200000 h |
| Operating system installed | RouterOS |
| Processor frequency | 800 MHz |
| Processor model | 98DX226S |
Power
| DC input voltage | 18 - 57 V |
| Power consumption (max) | 34 W |
| Power source | DC |
| Power supply included | Yes |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | No |
Operational conditions
| Operating temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Depth | 206.1 mm |
| Height | 44 mm |
| Width | 200 mm |
Certificates
| Certification | CE, EAC, ROHS |
