The RB260GSP is a small SOHO switch, which features power output on it’s ethernet ports. Ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. The RB260GSP has five Gigabit Ethernet ports and one SFP cage, switching is done by an Atheros Switch Chip. The device is running an operating system designed specifically for MikroTik Switch products - SwOS.
General
| Unit Calculated Weight | 0.782 kg |
| Unit Calculated Volume | 0.002887 cubm |
| Units per Shipping Box | 20 |
| Units per Pallet | 0 |
| Summary | Mikrotik RB260GSP. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5, Power connector: DC-in jack. Power over Ethernet (PoE) |
| Unit Box Height | 0.075 |
| Unit Box Length | 0.22 |
| Unit Box Width | 0.147 |
| Model name | CSS106-1G-4P-1S |
Management features
| Switch type | Managed |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| SFP module slots quantity | 1 |
Network
| 10G support | No |
Design
| LED indicators | Yes |
| Product colour | White |
| Rack mounting | No |
Power
| Input voltage | 8 - 30 V |
| Power consumption (typical) | 6 W |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 1 |
Operational conditions
| Operating temperature (T-T) | -25 - 65 °C |
Weight & dimensions
| Depth | 139 mm |
| Height | 28 mm |
| Weight | 212 g |
| Width | 113 mm |
