Eight 1G Ethernet ports and two SFP+ ports for 10G fiber connectivity. Portable, powerful and extremely cost-effective – this switch is an instant classic!
Cloud Smart Switch 610-8G-2S+IN is our answer to the everlasting demand for more power in a small and simple package. It comes with the lightweight SwOS which is easy to configure from your web browser. It gives you all the basic functionality for a managed switch, and more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields.
General
| Unit Calculated Weight | 1.02 kg |
| Unit Calculated Volume | 0.004586 cubm |
| Units per Shipping Box | 10 |
| Units per Pallet | 0 |
| Summary | Mikrotik CSS610-8G-2S+IN. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. DC input voltage: 12 - 57 V. Power over Ethernet (PoE) |
| CnCode | 85176200 |
| Unit Box Height | 0.06 |
| Unit Box Length | 0.315 |
| Unit Box Width | 0.2 |
| Model name | CSS610-8G-2S+IN |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 2 |
Network
| 10G support | Yes |
Design
| International Protection (IP) code | IP20 |
| LED indicators | Yes |
| Product colour | White |
Performance
| Internal memory | 0.64 MB |
| Mean time between failures (MTBF) | 200000 h |
| Memory type | Flash |
| Operating system installed | SwitchOS Lite |
Power
| DC input voltage | 12 - 57 V |
| Power consumption (max) | 11 W |
| Power source | DC/PoE |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
Operational conditions
| Operating temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Depth | 167 mm |
| Height | 46 mm |
| Width | 200 mm |
