The Thunderbolt™ 3 to HDMI™ 2.0 Dual Monitor 4K 60Hz lets users easily connect two HDMI™ 2.0 Screens to any device with a Thunderbolt™ 3 interface. This unique adapter is compatible with both Mac OS Sierra™ and Windows™ 10. The output resolution supported is up to 4K @ 60Hz for Single Screen and Dual Screen setups. It is fully Plug & Play, so no need for driver installation. This stylish adapter has a beautiful Brushed Aluminum Casing making it strong and light.
It is also very slim, 16 mm, making it easy to carry with you.
Multiply your screen area with your tablet, desktop PC or Ultrabook. With multiple monitors your computer will become more useful and you will become more efficient and accomplish more. With 2 displays delivering 4 K performance, you can have four times the screen space compared to 1080p.
Check out the downloads tab for more information
- Connect 2 UHD Screens to your Thunderbolt 3 output
- Supports resolutions 2 x 3840 x 2160 at 60Hz
- Works on Windows and MAC OS
General
| Unit Calculated Weight | 0.15 kg |
| Unit Calculated Volume | 0.0008697 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | CLUB3D Thunderbolt 3 to Dual HDMI 2.0 Adapter. Video port type: USB Type-C, Video out: 2x HDMI, Connector(s): HDMI 2.0. Maximum resolution: 3840 x 2160 pixels, Product colour: Grey, Silver, Maximum refresh rate: 60 Hz. Power consumption (typical): 15 W. Dimensions (WxDxH): 93 x 56 x 16 mm, Weight: 91 g. Package length: 28 cm, Package width: 80 mm, Package depth: 35 mm |
| Unit Box Height | 0.355 |
| Unit Box Length | 0.07 |
| Unit Box Width | 0.035 |
| Model name | Thunderbolt 3 to Dual HDMI 2.0 Adapter |
| Model | CSV-1574 |
Ports & interfaces
| Connector(s) | HDMI 2.0 |
| DC-in jack | No |
| HDMI version | 2.0 |
| Video out | 2x HDMI |
| Video port type | USB Type-C |
| Video ports quantity | 2 |
Features
| 3D | Yes |
| Cable length | 0.27 m |
| Easy to install | Yes |
| Full HD | Yes |
| HDCP | Yes |
| HD-Ready | Yes |
| Mac compatibility | Yes |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 3840 x 2160 pixels |
| Product colour | Grey,Silver |
| Windows operating systems supported | Windows 10/Windows 10 Education/Windows 10 Education x64/Windows 10 Enterprise/Windows 10 Enterprise x64/Windows 10 Home/Windows 10 Home x64/Windows 10 IOT Core/Windows 10 Pro/Windows 10 Pro x64 |
Power
| Power consumption (typical) | 15 W |
| USB powered | Yes |
Weight & dimensions
| Dimensions (WxDxH) | 93 x 56 x 16 mm |
| Weight | 91 g |
Packaging data
| Package depth | 35 mm |
| Package length | 280 mm |
| Package type | Box |
| Package width | 80 mm |
| Paper/cardboard packaging weight | 45 g |
| Plastic packaging weight | 5 g |
| Total paper/cardboard packaging weight | 0 g |
| Total plastic packaging weight | 0 g |
Technical details
| Connector 1 | Thunderbolt 3 |
| Connector 2 | 2 x HDMI 2.0 |
| Maximum video resolution | 3840 x 2160 pixels |
Logistics data
| Harmonized System (HS) code | 8473 3020 |
| Products per master (outer) case | 10 pc(s) |
