• 8-PORT USB Type-C®: Expand the connectivity of a USB Type-C®
computer by adding three USB 10Gbps Ports (2x USB Type-A, 1x
Type-C®) a Power Delivery 3.0 USB Type-C® Port Max. 100Watt.
• 1 GBASE-T GIGABIT ETHERNET: Features a 1Gb network controller
that delivers speeds of 10/100/1000Mbps; For laptops / devices without
a USB Type-A or Ethernet, such as MacBook /iPad Air / Pro; USB
Type-C® connectivity while providing power for PD3.0 charging.
• RELIABLE PERFORMANCE: USB bus powered or via external USB
Type-C® power adapter; 100W Power Delivery 3.0 pass through with
15W dedicated to the functioning of this product,
- Support DP1.4 Alt mode
- Support 2x 4K/30Hz simultaneously
- Support 8/10/12bpc color depth output
- Support HDCP 2.2&HDCP1.4
- 1x USB Type-C® data port and 2x USB Type-A 2 support max 10Gbps data transmission
- USB Type-A data port and 1 USB Type-A port support max 7.5W([email protected]) downstream charging per port
- Ethernet Support 10M/100M/1000M bandwidth
- SD/TF card slots support to transmission data with max 104MBps, allow SD/Micro SD to work simultaneously
- Support Fast Role Swap of PD 3.0, the connected device will not get disconnected while plugging out PD Adapter
- 2x USB Type-A port share max 9W(5V/1.8A)
General
| Unit Calculated Weight | 0.14 kg |
| Unit Calculated Volume | 0.000567 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | CLUB3D 8-1 Portable Dock USB Type-C® 10Gbps to HDMI™ and DisplayPort™ 8K30Hz PD Max.100Watt. Connectivity technology: Wired, Host interface: USB Type-C, USB Power Delivery up to: 100 W. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Black, Compatible memory cards: MicroSD (TransFlash), SD. Power source type: USB, Power connector: USB Type-C, USB cable length: 0.17 m. Weight: 107 g |
| Unit Box Height | 0.27 |
| Unit Box Length | 0.06 |
| Unit Box Width | 0.035 |
| Model | CSV-2551 |
Ports & interfaces
| Connectivity technology | Wired |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| HDCP version | 1.4/2.2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Host interface | USB Type-C |
| Microphone in | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
Network
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
Performance
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash)/SD |
| Product colour | Black |
Power
| Power connector | USB Type-C |
| Power source type | USB |
| USB cable length | 0.17 m |
Software
| Mac operating systems supported | Yes |
| Windows operating systems supported | Yes |
Weight & dimensions
| Weight | 107 g |
Packaging data
| Package depth | 240 mm |
| Package height | 35 mm |
| Package weight | 137 g |
| Package width | 60 mm |
| Quantity per pack | 1 pc(s) |
Packaging composition
| Paper/cardboard packaging weight | 28 g |
| Plastic packaging weight | 2 g |
| Total paper/cardboard packaging weight | 0 g |
| Total plastic packaging weight | 0 g |
Technical details
| Compliance certificates | CE/Federal Communications Commission (FCC)/RoHS |
Logistics data
| Harmonized System (HS) code | 8473 3020 |
