DUAL GEFORCE RTX™ 5060 Ti White Edition
Dual Fans, Perfect Fit
ASUS Dual GeForce RTX™ 5060 Ti White Edition combines powerful thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards — including two Axial-tech fans for optimizing airflow to the heatsink. Designed in a compact 2.5-slot form factor, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build.
Cooling
2.5-slot Design
A carefully designed shroud, heatsink, and heatpipe layout enables the two Axial-tech fans to leverage chassis side-panel ventilation, delivering thermal performance that beyond the compact size.
Axial-tech Upgrades
Two tried-and-true Axial-tech fans feature a smaller hub facilitates longer blades and a barrier ring to increase downward air pressure.
General
| Unit Calculated Weight | 1.27 kg |
| Product Net Weight | 0.656 kg |
| Unit Calculated Volume | 0.006978 cubm |
| Units per Shipping Box | 8 |
| Units per Pallet | 0 |
| Model | DUAL-RTX5060TI-O16G-WHITE |
| Summary | ASUS Dual -RTX5060TI-O16G-WHITE. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 5060 Ti. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR7, Memory bus: 128 bit. Maximum resolution: 7680 x 4320 pixels. OpenGL version: 4.6. Interface type: PCI Express 5.0. Cooling type: Active, Number of fans: 2 fan(s) |
| CnCode | 84718000 |
| Unit Box Height | 0.07 |
| Unit Box Length | 0.37 |
| Unit Box Width | 0.22 |
Processor
| CUDA | Yes |
| CUDA cores | 4608 |
| Graphics processor | GeForce RTX 5060 Ti |
| Graphics processor family | NVIDIA |
| Maximum displays per videocard | 4 |
| Maximum resolution | 7680 x 4320 pixels |
| Parallel processing technology support | Not supported |
| Processor boost clock speed | 2602 MHz |
| Processor frequency (OC mode) | 2632 MHz |
Memory
| Data transfer rate | 28 Gbit/s |
| Discrete graphics card memory | 16 GB |
| Graphics card memory type | GDDR7 |
| Memory bus | 128 bit |
Ports & interfaces
| DisplayPort version | 2.1b |
| DisplayPorts quantity | 3 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| Interface type | PCI Express 5.0 |
Performance
| HDCP | Yes |
| HDCP version | 2.3 |
| NPU performance up to | 759 TOPs |
| OpenGL version | 4.6 |
| Overclocked (OC) edition | Yes |
| TV tuner integrated | No |
Design
| Cooling technology | ASUS Axial-tech |
| Cooling type | Active |
| Number of fans | 2 fan(s) |
| Number of slots | 2.5 |
| Product colour | White |
Power
| Minimum system power supply | 550 W |
| Supplementary power connectors | 1x 8-pin |
Weight & dimensions
| Depth | 50 mm |
| Height | 120 mm |
| Length | 229 mm |
| Weight | 656 g |
Packaging data
| Package depth | 217 mm |
| Package height | 66 mm |
| Package type | Box |
| Package weight | 1116 g |
| Package width | 364 mm |
Packaging content
| Manual | Yes |
