Versatile Antennas Deployment
Adapt to any environment effortlessly by selecting the antenna type that suits your needs. Whether you require long-distance connectivity or need to cover multiple endpoints, easily switch between external omni, internal directional, or custom antenna configurations with just a few clicks in the software.
Auto-Sensing Plug & Play—No Expertise Needed
Automatically detects the attachment and removal of antennas (included) in auto mode and seamlessly switches between the internal and external antennas with zero configuration.
Outdoor-Ready IP66 Weatherproof Design
The EAP725-Outdoor features an IP66 weatherproof rating, ensuring reliable protection against heavy rain, dust, and harsh weather conditions.
Seamless Connectivity with Mesh and Roaming
Ensures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.
Works with Omada SDN for One-Click Setup
Omada SDN allows users to quickly set up the EAP725-Outdoor through automatic device identification and one‑click adoption.
Empowering Businesses with Reliable Omada SDN Solutions
Omada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.
- Directional and Omnidirectional Antennas: Freely switch between modes via software for optimal signal control
- Plug & Play Auto-Sensing Antennas: Automatically detects antenna changes and switches between internal and external antennas as needed
- 4-Stream Dual-Band Wi-Fi 7: Up to 5.0 Gbps
- 1× 2.5G PoE Port: Flexible PoE deployment reduces costs by delivering power and data over a single Ethernet cable
- Outdoor-Ready Durability: Features an IP66-rated weatherproof enclosure and 6kV lightning protection
- Quick and Easy Setup: Features wall/pole mounting with Omada SDN for one-click setup
- Advanced Features: Centralized management, mesh, and seamless roaming
General
| Summary | TP-Link Omada EAP725-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 5000 Mbit/s. Security algorithms: OWE, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal,.... Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 18.4 W |
| Unit Box Height | 0.084 |
| Unit Box Length | 0.25 |
| Unit Box Width | 0.204 |
| Name | WRL ACCESS POINT 5000MBPS/OMADA EAP725-OUTDOOR TP-LINK |
| Model name | EAP725-Outdoor |
Features
| BeamForming | Yes |
| Quality of Service (QoS) support | Yes |
| Band steering | Yes |
| Wireless isolation | Yes |
| Rate limiting | Yes |
| Virtual LAN features | Management VLAN |
| VLAN support | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Cabling technology | 10/100/1000/2500Base-T |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11be/IEEE 802.11g/IEEE 802.11k/IEEE 802.11n/IEEE 802.11r/IEEE 802.11v/IEEE 802.1x/IEEE 802.3at |
| Ethernet LAN data rates | 10/100/1000/2500 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4324 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 688 Mbit/s |
| Maximum data transfer rate | 5000 Mbit/s |
| 5 GHz | Yes |
| 6 GHz | No |
| 2.4 GHz | Yes |
Security
| Schedule access | Yes |
| Number of SSID supported | 16 |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| MAC address filtering | Yes |
| Security algorithms | OWE/SNMP/SNMPv2/SNMPv3/SSH/WPA2-Enterprise/WPA2-Personal/WPA3-Enterprise/WPA3-Personal/WPA-Enterprise/WPA-Personal |
Management features
| Cloud-managed | Yes |
| Syslog | Yes |
| Web-based management | Yes |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Power consumption (max) | 18.4 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+ |
Design
| LED indicators | Status |
| Reset button | Yes |
| International Protection (IP) code | IP66 |
| Product colour | White |
| Placement | Pole,Wall |
Antenna
| Antenna gain level (max) | 13.2 dBi |
| Antennas quantity | 8 |
| Antenna type | Internal & external |
Certificates
| Compliance certificates | BSMI/CE/Federal Communications Commission (FCC)/Industry Canada (IC)/JRF/NCC/RoHS/VCCI |
Weight & dimensions
| Weight | 1330 g |
| Height | 55 mm |
| Depth | 160 mm |
| Width | 208 mm |
Packaging content
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
Operational conditions
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
