Ideal for Small Business Networking Use
Combines 4G Internet access, Wi-Fi 6 wireless technology and 4 Gigabit PoE+ out ports all in one device.
Dual SIM Ensures Business Continuity
In scenarios involving automatic failover mechanisms, backup WAN connections, and various network switching situations, the system ensures business continuity.
Software Defined Networking (SDN) with Cloud Access
Centralised cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloudbased controller offering the Essentials version of cloud services for free, reducing maintaince costs.
- 5 Gigabit Ethernet Ports: Provide high-speed wired connectivity
- 5 High-Gain Detachable Antennas: Extend and concentrate the Wi-Fi signals
- Centralised Management: Cloud access and the Omada app for easy management
General
| Unit Calculated Weight | 1.97 kg |
| Unit Calculated Volume | 0.005684 cubm |
| Units per Shipping Box | 1 |
| Summary | TP-Link Omada ER706WP-4G. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), WLAN data transfer rate (max): 300 Mbit/s, Modulation: OFDMA. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, VPN support: IPsec VPN PPTP VPN L2TP VPN OpenVPN WireGuard VPN. Mobile network generation: 4G, 4G bands supported: 800,850,900,1500,1700,1800,1900,2000,2300,2400,2500,2600,3400,3500,3600,3700 MHz, SIM card type: NanoSIM. Security algorithms: IPSec, SNMP, SNMPv2, SNMPv3, WPA, WPA2, WPA3-Personal, NAT functionality: DHCP, PPPoE, L2TP, PPTP |
| CnCode | 85176200 |
| Unit Box Height | 0.28 |
| Unit Box Length | 0.29 |
| Unit Box Width | 0.07 |
| Model name | ER706WP-4G |
| Model | ER706WP-4G |
Wireless LAN features
| Modulation | OFDMA |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 300 Mbit/s |
WAN connection
| 3G/4G USB modem compatibility | Yes |
| DSL WAN | Yes |
| Ethernet WAN | Yes |
| SIM card slot | Yes |
| WAN connection type | RJ-45 |
Network
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Port forwarding | Yes |
| SSID-based VLAN assignment | Yes |
| Static route | Yes |
| VPN Passthrough | Yes |
| VPN support | IPsec VPN PPTP VPN L2TP VPN OpenVPN WireGuard VPN |
| VPN tunnels quantity | 50 |
Mobile network
| 4G bands supported | 1500/1700/1800/1900/2000/2300/2400/2500/2600/3400/3500/3600/3700/800/850/900 MHz |
| Dual SIM support | Yes |
| Mobile network generation | 4G |
| Short Message Service (SMS) | No |
| SIM card type | NanoSIM |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 5 |
| USB port | Yes |
Management features
| Intelligent Mesh technology | Yes |
| MU-MIMO technology | Yes |
| Reset button | Yes |
| Web-based management | Yes |
Security
| Filtering | Yes |
| NAT functionality | DHCP, PPPoE, L2TP, PPTP |
| Network address translation (NAT) | Yes |
| Security algorithms | IPSec/SNMP/SNMPv2/SNMPv3/WPA/WPA2/WPA3-Personal |
| URL filtering | Yes |
Protocols
| DHCP client | Yes |
| DHCP server | Yes |
Design
| LED indicators | LTE,Power,Status,System,WLAN |
| Product colour | Black |
| Product type | Desktop/pole router |
| Wall mountable | Yes |
Packaging content
| Antenna included | Yes |
Antenna
| Antenna design | External |
| Antenna direction type | Directional |
| Antenna gain level (max) | 4.5 dBi |
| Antennas quantity | 5 |
| Detachable antenna(s) | Yes |
Features
| Flash memory | 256 MB |
| Internal memory | 512 MB |
| Internal memory type | DDR4 |
Power
| Power over Ethernet (PoE) | Yes |
| Power source type | DC,PoE |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Depth | 131 mm |
| Height | 35 mm |
| Width | 226 mm |
