Elementum E5 550 W is a stable PSU with an 80 PLUS® certificate that will work well both for PC integrators as well as for home assembly. It is equipped with the proper wiring for powering a graphics card with its two PCI-E connections (8- and 6-pin). And thanks to its deep black hues, it will look appealing even for less visually impressive PCs.
Elementum E5 550 W
Elementum E5 550 W is a stable PSU with an 80 PLUS® that will protect your PC both from power surges at a steady 550 W. It will work well both as a product for PC integrator use as well as for home assembly.
This PSU offers multiple protections (OVP, UVP, SCP, OPP and SIP) and so your PC will be able to resist, among others, short-circuits and unexpected system overload. A 12-centimeter fan is in charge of keeping things cool – which in practical terms means that even a computer under heavy load will still allow you to enjoy a pleasant silence.
General
| Unit Calculated Weight | 1.64 kg |
| Unit Calculated Volume | 0.005443 cubm |
| Units per Shipping Box | 10 |
| Units per Pallet | 0 |
| Model name | Elementum E5 550 W |
| Summary | ENDORFY Elementum E5 550W. Total power: 550 W, AC input voltage: 230 V, Power protection features: Over power. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 45 cm, SATA power cable length: 410 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Cables included: AC |
| Unit Box Height | 0.185 |
| Unit Box Length | 0.1 |
| Unit Box Width | 0.24 |
Power
| AC input voltage | 230 V |
| Power protection features | Over power |
| Total power | 550 W |
Ports & interfaces
| ATX power connector (12+4 pin) | Yes |
| Motherboard power cable length | 450 mm |
| Motherboard power connector | 24-pin ATX |
| Number of EPS connectors | 2 |
| Number of SATA power connectors | 2 |
| PCI Express connector | Yes |
| PCI Express power cable length | 460 mm |
| PCI Express power connectors (6+2 pin) | 1 |
| PCI Express power connectors (6-pin) | 1 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| SATA power cable length | 410 mm |
Performance
| 80 PLUS certification | 80 PLUS |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
Design
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Product colour | Black |
Packaging content
| Cables included | AC |
Weight & dimensions
| Depth | 140 mm |
| Height | 87 mm |
| Width | 150 mm |
