Experience the next level of gaming immersion with GIGABYTE's AMD graphics cards. Crafted to deliver uncompromising performance and stunning visuals, our GPUs redefine gaming excellence. Featuring advanced cooling solutions and innovative technologies, GIGABYTE AMD graphics cards empower gamers to push the boundaries of what's possible, delivering unmatched gaming experiences.
- Powered by Radeon RX 9060 XT
- Integrated with 16GB GDDR6 128bit memory interface
- WINDFORCE cooling system
- RGB Lighting
- Dual BIOS (Performance / Silent)
- Reinforced structure
General
| Unit Calculated Weight | 1.31 kg |
| Product Net Weight | 0.8 kg |
| Unit Calculated Volume | 0.00692 cubm |
| Units per Shipping Box | 10 |
| Model | GV-R9060XTGAMING OC-16GD |
| Summary | GIGABYTE Radeon RX 9060 XT GAMING OC 16G Graphics Card - 16GB GDDR6, 128bit, PCI-E 5.0, 3320 MHz Core Clock, 2 x DisplayPort, 1 x HDMI, GV-R9060XTGAMING OC-16GD. Graphics processor family: AMD, Graphics processor: Radeon RX 9060 XT. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR6, Memory bus: 128 bit, Memory clock speed: 20000 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12.0, OpenGL version: 4.6. Interface type: PCI Express x16 5.0. Cooling type: Active, Number of fans: 3 fan(s), Illumination colour: Multi |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.361 |
| Unit Box Width | 0.187 |
Processor
| CUDA | No |
| Graphics processor | Radeon RX 9060 XT |
| Graphics processor family | AMD |
| Maximum displays per videocard | 4 |
| Maximum resolution | 7680 x 4320 pixels |
| Parallel processing technology support | Not supported |
| Processor boost clock speed | 3320 MHz |
| Processor boost clock speed (Gaming mode) | 2780 MHz |
| Stream processors | 2048 |
Memory
| Data transfer rate | 20 Gbit/s |
| Discrete graphics card memory | 16 GB |
| Graphics card memory type | GDDR6 |
| Memory bus | 128 bit |
| Memory clock speed | 20000 MHz |
Ports & interfaces
| DisplayPorts quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| Interface type | PCI Express x16 5.0 |
Performance
| DirectX version | 12.0 |
| Dual Link DVI | No |
| OpenGL version | 4.6 |
| Overclocked (OC) edition | Yes |
| TV tuner integrated | No |
| Warranty period | 3 year(s) |
Design
| Cooling technology | GIGABYTE WINDFORCE 3X |
| Cooling type | Active |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Illumination | Yes |
| Illumination colour | Multi |
| Number of fans | 3 fan(s) |
| Product colour | Black |
Power
| Minimum system power supply | 450 W |
| Supplementary power connectors | 1x 8-pin |
| Thermal Design Power (TDP) | 151 W |
Weight & dimensions
| Depth | 40 mm |
| Height | 118 mm |
| Length | 281 mm |
| Weight | 840 g |
Packaging data
| Package depth | 354 mm |
| Package height | 75 mm |
| Package type | Box |
| Package weight | 1290 g |
| Package width | 182.5 mm |
Logistics data
| Products per shipping (inner) case | 1 pc(s) |
