Now with airOS®8 and airView®
airOS®8 provides powerful features, including airMAX ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
High-Gain, Directional Antenna
The LiteBeam AC provides 23 dBi of gain for long-distance connectivity and uses a directional antenna pattern for improved noise immunity.
Breakthrough Industrial Design
Featuring the freedom of three-axis alignment, the LiteBeamM fully assembles in seconds – no tools needed. Only a single wrench is required for pole-mounting.
Compact in Size, Light in Weight
A lightweight form factor contained within ultra-compact packaging, the LiteBeam AC is ideal for shipping and logistics.
- Improved Radio Design
- Improved Mounting
- Improved Surge Protection
- Management WiFi Radio/UNMS mobile app
- AirOS 8
General
| Unit Calculated Weight | 1.71 kg |
| Unit Calculated Volume | 0.007941 cubm |
| Units per Shipping Box | 8 |
| Summary | Ubiquiti LiteBeam AC Gen2. Antenna design: External, Antenna gain level (max): 23 dBi. Wi-Fi band: Single-band (5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), Frequency band: 5.15 - 5.875 GHz. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.11ac, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3u. Connectivity technology: Wired & Wireless. Product type: Network bridge, Material: Polycarbonate (PC), SGCC, Mounting type: Pole |
| Unit Box Height | 0.3 |
| Unit Box Length | 0.17 |
| Unit Box Width | 0.14 |
| Model | UBIQUITI airMAX LiteBeam 5AC Long-Range (LBE-5AC-GEN2) |
Antenna
| Antenna design | External |
| Antenna gain level (max) | 23 dBi |
| Antennas quantity | 1 |
Wireless LAN features
| Frequency band | 5.15 - 5.875 GHz |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
Network
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.11ac/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ac/IEEE 802.3u |
Ports & interfaces
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Internal memory | 64 MB |
| LED indicators | LAN/Power |
| Material | Polycarbonate (PC)/SGCC |
| Mounting type | Pole |
| Processor family | Atheros |
| Processor manufacturer | Qualcomm |
| Processor model | MIPS 74Kc |
| Product colour | White |
| Product type | Network bridge |
| Rack mounting | No |
| RAM type | DDR2 |
| Reset button | Yes |
Power
| Power consumption (max) | 7 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 24 V |
| Power source type | PoE |
Operational conditions
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -40 - 70 °C |
Certificates
| Compliance certificates | RoHS |
Weight & dimensions
| Depth | 272.5 mm |
| Height | 271.95 mm |
| Weight | 800 g |
| Width | 358 mm |
Sustainability
| Sustainability compliance | Yes |
