DISPLAY LCD 55" OM55N-DS/LH55OMNDSGBXEN SAMSUNG
General
| Unit Calculated Weight | 52 kg |
| Unit Calculated Volume | 0.5009 cubm |
| Units per Pallet | 0 |
| Summary | Samsung OM55N-DS. Product design: Digital signage flat panel. Display diagonal: 139.7 cm (55"), Display technology: LCD, Display resolution: 1920 x 1080 pixels, Display brightness: 3000 cd/m², HD type: Full HD. Wi-Fi. Operating system installed: Tizen 5.0. Product colour: Black |
| Unit Box Height | 1.46 |
| Unit Box Length | 0.94 |
| Unit Box Width | 0.365 |
| Model name | OM55N-DS |
Display
| Colour gamut | 72 % |
| Contrast ratio (typical) | 6000:1 |
| Display brightness | 3000 cd/m² |
| Display diagonal | 55 " |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LCD |
| Dynamic contrast ratio marketing name | Mega Contrast |
| HD type | Full HD |
| Horizontal scan range | 15 - 135 kHz |
| Panel type | VA |
| Pixel frequency (max) | 594 MHz |
| Pixel pitch | 0.63 x 0.63 mm |
| Response time | 6 ms |
| RGB colour space | NTSC |
| Touchscreen | No |
| Vertical scan range | 24 - 75 Hz |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Ports & interfaces
| DVI port | No |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Infrared data port | Yes |
| Remote (IR) input | 1 |
| RS-232 interface | Yes |
| USB port | Yes |
| USB ports quantity | 2 |
Design
| Bezel width (bottom) | 22.8 mm |
| Bezel width (side) | 22.8 mm |
| Bezel width (top) | 22.8 mm |
| Orientation | Vertical |
| Placement supported | Indoor/outdoor |
| Product colour | Black |
| Product design | Digital signage flat panel |
| Screen shape | Flat |
Performance
| HDCP | Yes |
| HDCP version | 2.2 |
| Purpose | Universal |
Power
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (sleep) | 0.5 W |
| Power consumption (typical) | 500 W |
Computer system
| Built-in processor | Yes |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Operating system installed | Tizen 5.0 |
Weight & dimensions
| Display depth | 69.5 mm |
| Display height | 1299 mm |
| Display weight | 42000 g |
| Display width | 726.8 mm |
Packaging data
| Package depth | 367 mm |
| Package height | 1466 mm |
| Package volume | 52000 cm³ |
| Package width | 940 mm |
Operational conditions
| Operating relative humidity (H-H) | 10 - 80 % |
| Operating temperature (T-T) | 0 - 40 °C |
Certificates
| Certification | Class A 60950-1 |
Network
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
Other features
| Flash memory | 8000 MB |
| RS-232 input ports | 1 |
