DISPLAY LCD 55" VM55B-U/LH55VMBUBGBXEN SAMSUNG
General
| Unit Calculated Weight | 28.8 kg |
| Unit Calculated Volume | 0.3068 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | Samsung VM55B-U. Display diagonal: 139.7 cm (55"), Display resolution: 1920 x 1080 pixels, Display technology: LED, Display brightness: 500 cd/m², HD type: Full HD, Operating hours (hours/days): 24/7. Product colour: Black |
| Unit Box Height | 0.83 |
| Unit Box Length | 1.395 |
| Unit Box Width | 0.265 |
| Model name | VM55B-U |
Display
| Colour gamut | 72 % |
| Contrast ratio (dynamic) | 45000:1 |
| Contrast ratio (typical) | 1200:1 |
| Display brightness | 500 cd/m² |
| Display diagonal | 55 " |
| Display resolution | 1920 x 1080 pixels |
| Display technology | LED |
| Haze rate | 25 % |
| HD type | Full HD |
| Horizontal scan range | 62.7 - 72.3 kHz |
| Operating hours (hours/days) | 24/7 |
| Panel type | IPS |
| Pixel pitch | 0.63 x 0.63 mm |
| Response time | 0.008 s |
| Vertical scan range | 57 - 63 Hz |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
Design
| Bezel width (bottom) | 1.25 mm |
| Bezel width (top) | 2.25 mm |
| Orientation | Horizontal/Vertical |
| Panel mounting interface | 600 x 400 mm |
| Placement supported | Indoor |
| Product colour | Black |
| VESA mounting | Yes |
| Wall mountable | Yes |
Ports & interfaces
| Audio input | Yes |
| Audio output | Yes |
| DisplayPort version | 1.2 |
| DisplayPorts in | 1 |
| DisplayPorts quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| HDCP | Yes |
| HDCP version | 2.2 |
| HDMI input ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| IR input ports quantity | 1 |
| RS-232 input ports | 1 |
| RS-232 output ports | 1 |
| USB port | Yes |
| USB ports quantity | 1 |
Power
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Energy consumption (SDR) per 1000 hours | 165 kWh |
| Energy efficiency class (SDR) | G |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 220 W |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | 10 - 90 °C |
Sustainability
| Certification | FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 ? EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14 |
Weight & dimensions
| Depth | 73.1 mm |
| Height | 684.3 mm |
| Weight | 21200 g |
| Width | 1213.5 mm |
Packaging data
| Mounting kit | Yes |
| Package depth | 257 mm |
| Package height | 844 mm |
| Package weight | 28800 g |
| Package width | 1398 mm |
Energy Efficiency
| Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1192452/fiches?language=EN |
| Energy efficiency class | G |
| EPREL Registration Number | 1192452 |
| EPREL Version Number | 3 |
