8 IP channel max, up to 12MP resolution
80Mbps record rate
VGA/HDMI up to 1-channel 12MP @30 fps; 6-channel 1080p @ 30 fps
1 SATA port, up to 16 TB 3.5” HDD, 10/100M LAN
No front panel control, no Alarm I/O, 2 USB
Smart 1U case (white), mouse included
ONVIF (profile T/S/G); CGI; SDK
Connected to the third-party network cameras
4-channel SMD Plus (AI by camera), secondary filtering for human and motor vehicle SMD Plus
Free IP monitoring software available
General
| Model | DHI-NVR2108-S3 |
| Number of Channels | 8 |
| Number of drives/bays | 1 |
| Unit Box Height | 0.095 |
| Unit Box Length | 0.365 |
| CPU | Embedded Linux |
| Unit Box Width | 0.265 |
| Power supply requirements | 12 VDC, 1.5 A |
| Power consumption | 10 Watts |
| Dimensions | 204.6 × 206.4 × 45.6 mm |
| Operating temperature range | –10 °C to +55 °C |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.009189 cubm |
| Product Net Weight | 0.42 kg |
| Unit Calculated Weight | 0.99 kg |
Mounting Type
| Desktop/pedestal | Yes |
| Rack | Yes |
Interface
| SATA | Yes |
Input/Output connectors
| 15pin D-sub | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| HDMI | 1 |
| RJ45 | 1 |
| USB 2.0 | 2 |
