Viper Gaming is very excited to reveal the first of our DDR5 generation, the Viper Venom DDR5 DRAM series! The Viper Venom DDR5 memory series is the first generation of our DDR5, made for insane system performance on DDR5 platforms! Viper Venom DDR5 memory modules are designed with groundbreaking technology to set benchmarks even higher than most extreme overclocked DDR4 modules and delivers twice as fast, doubling the current bandwidth of DDR4.
The Viper Venom DDR5 modules have innovative onboard power management ICs for more efficient operation and lower power consumption, along with onboard thermal management technology providing longer life for the modules. With a limited lifetime warranty, this cutting-edge technology will enable blazing quick application start-ups while expanding your system’s capabilities.
Viper Venom DDR5 DRAM modules generate superior improvements towards user experience over previous memory lines and will be the next ultimate solution for gaming enthusiasts globally!
- Series: Viper Venom DDR5 series
- Edition: Matte Black with Red Viper logo / Silver name plate
- Aluminum heat spreader with unique and specific design element
- Feature Overclock: XMP 3.0 overclocking supported
- Compatibility: Tested across latest DDR5 platforms for reliably on high performance
- On-Die ECC
- Thermal sensor
General
| Summary | Patriot Memory Viper Venom PVV516G600C36. Component for: PC, Internal memory: 16 GB, Memory layout (modules x size): 1 x 16 GB, Internal memory type: DDR5, Memory form factor: 288-pin DIMM, CAS latency: 36, Product colour: Black, White |
| Unit Box Height | 0.015 |
| Unit Box Length | 0.15 |
| Unit Box Width | 0.07 |
| Name | MEMORY DIMM 16GB DDR5-6000/PVV516G600C36 PATRIOT |
Features
| Cooling type | Heatsink |
| Product colour | Black/White |
| AMD Extended Profiles for Overclocking (EXPO) | Yes |
| Intel Extreme Memory Profile (XMP) version | 3.0 |
| Intel Extreme Memory Profile (XMP) | Yes |
| On-Die ECC | Yes |
| ECC | No |
| Memory layout (modules x size) | 1 x 16 GB |
| Component for | PC |
| Memory data transfer rate | 6000 MT/s |
| Memory form factor | 288-pin DIMM |
| Memory voltage | 1.35 V |
| CAS latency | 36 |
| Buffered memory type | Unregistered (unbuffered) |
| Internal memory | 16 GB |
| Internal memory type | DDR5 |
Sustainability
| Compliance certificates | BSMI/CE/Federal Communications Commission (FCC)/RoHS/UKCA |
Weight & dimensions
| Weight | 52 g |
| Height | 43 mm |
| Depth | 7 mm |
| Width | 137 mm |
Packaging data
| Package type | Box |
| Package weight | 73 g |
| Package height | 148 mm |
| Package depth | 13.7 mm |
| Package width | 70 mm |
ELKO Verified Logistics Data
| Unit Height | 1.5 cm |
| Unit Depth | 15 cm |
| Unit Width | 7 cm |
| Units per Pallet | 0 |
| Units per Shipping Box | 200 |
| Product Net Weight | 0.052 kg |
| Unit Calculated Weight | 0.075 kg |
ELKO Internal Logistics Data
| Shipping Box Width | 33 cm |
| Shipping Box Depth | 41 cm |
| Shipping Box Height | 34 cm |
| Shipping Box Weight | 15 kg |
| Unit Calculated Volume | 0.00023 cubm |
