An all-in-one edge storage solution
The compact 1U 4-bay Synology RackStation RS822+/RS822RP+ with its storage and connectivity expandability coupled with the powerful Synology DiskStation Manager (DSM) operating system is an ideal edge storage solution for branch offices and small and medium-sized businesses.
Built for reliability
RS822+/RS822RP+ comes with four Gigabit RJ-45 ports which can be bonded with Link Aggregation to enable automatic network failover and load balancing.
Two RS822+/RS822RP+ units can be paired using Synology High Availability to form a reliable active/passive server cluster, maximizing service uptime.
Furthermore, the RS822RP+ features a redundant power supply for an extra edge in service continuity.
Room for expansion
Easily adjust the RS822+/RS822RP+ to match your usage environment, whether it needs performance, faster networking, or higher storage capacity.
All-in-one data management platform
The RS822+/RS822RP+ is designed to support small deployments in tackling common applications such as file management, data backup, and surveillance.
Edge storage for distributed teams
Provide secure and convenient cross-platform file access, sharing, and synchronization across multiplelocations.
Multi-endpoint data protection
Design an effective backup strategy to maximize system availability with a host of native and license-free solutions.
Smart surveillance for small deployments
Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.
Works best with Synology drives
Enjoy high sustained performance and reliability with enterprise-grade drives designed for Synology NAS and featuring built-in data protection.
Powered by Synology DSM
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based DSM operating system.
- 2103/1074 MB/s sequential read/write throughput
- Scale up to 8 drives with Synology Expansion Unit RX418
- Built-in 4 x 1GbE ports with 10/25 GbE expansion option
- Up to 32 GB DDR4 ECC
General
| Unit Calculated Weight | 11.6 kg |
| Unit Calculated Volume | 0.07315 cubm |
| Units per Shipping Box | 1 |
| Summary | Synology RackStation RS822RP+. Type: NAS. Chassis type: Rack (1U). Device class: Small & Medium Business. Processor family: Ryzen Embedded, Processor model: V1500B, Processor frequency: 2.2 GHz. Internal memory: 2 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: DiskStation Manager |
| Unit Box Height | 0.585 |
| Unit Box Length | 0.61 |
| Unit Box Width | 0.205 |
| Model name | RS822RP+ |
Storage
| Hot-swap drive bays | Yes |
| Installed storage drive type | No |
| Number of storage drives supported | 4 |
| Online RAID expansion | Yes |
| Online RAID migration | Yes |
| RAID levels | 0/1/10/5/6/JBOD |
| RAID support | Yes |
| Storage drive sizes supported | 2.5/3.5 " |
| Storage drives installed | No |
| Supported file systems | BTRFS/exFAT/ext3/ext4/FAT32/HFS+/NTFS |
| Supported storage drive interfaces | Serial ATA II,Serial ATA III |
| Supported storage drive types | HDD & SSD |
| Total installed storage capacity | 0 TB |
Processor
| L2 cache | 2 MB |
| L3 cache | 4 MB |
| Number of processors supported | 1 |
| On-board graphics card model | Not available |
| Processor cores | 4 |
| Processor family | Ryzen Embedded |
| Processor frequency | 2.2 GHz |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Processor manufacturer | AMD |
| Processor model | V1500B |
| Processor threads | 8 |
Memory
| ECC | Yes |
| Internal memory | 2 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 32 GB |
| Memory form factor | SO-DIMM |
| Memory slots | 2 |
Network
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| iSCSI support | Yes |
| Link aggregation | Yes |
| Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Wake-on-LAN ready | Yes |
| WLAN adapter supported | Yes |
Ports & interfaces
| Concurrent connections | 500 |
| eSATA ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB port | Yes |
Design
| Chassis type | Rack (1U) |
| Cooling type | Active |
| Drive bay locking | Yes |
| Fan diameter | 40 mm |
| LED indicators | Alarm/HDD/Power/Status |
| Number of fans | 2 fan(s) |
| Product colour | Grey |
Performance
| Access Control List (ACL) | Yes |
| Backup features | Cloud/iSCSI LUN |
| Backup function | Yes |
| Browser supported | Google Chrome, Firefox, Microsoft Edge, Safari |
| Built-in FTP server | Yes |
| Built-in iTunes server | Yes |
| Device class | Small & Medium Business |
| Hot spare | Yes |
| Multilingual support | Yes |
| Noise level | 38.8 dB |
| Number of users | 2048 user(s) |
| On/off switch | Yes |
| Reset button | Yes |
| Security algorithms | HTTPS/SSH/SSL/TLS |
| Share folder | SMB/AFP/NFS/FTP/WebDAV |
| Snapshot | Yes |
| System log | Yes |
| Third-party support | Yes |
| Type | NAS |
Software
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Operating system installed | DiskStation Manager |
| Windows operating systems supported | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (HDD standby) | 16.7 W |
| Power consumption (typical) | 47.69 W |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 150 W |
| Redundant power supply (RPS) support | Yes |
Weight & dimensions
| Depth | 518.6 mm |
| Height | 44 mm |
| Weight | 8000 g |
| Width | 480 mm |
Packaging content
| Cables included | AC |
| Power cables quantity | 2 |
Operational conditions
| Operating altitude | 0 - 5000 m |
| Operating relative humidity (H-H) | 8 - 80 % |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Certification | FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL |
| Compliance certificates | RoHS |
