- > 16 × RJ-45 10/100/1000 ports.
- > The all-gigabit ports transmit data without lag.
- > Features aggregation mode which aggregates uplink ports.
- > Features isolation mode which isolates all the ports from each other.
- > With its solid full metal design, the device has great heat dissipation and no fan.
- > Supports rack mount, wall mount and desktop mount.
General
| Unit Calculated Weight | 1.4 kg |
| Unit Calculated Volume | 0.005724 cubm |
| Units per Shipping Box | 1 |
| Summary | Dahua Technology S3016-16GT. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 16000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u. Rack mounting, Form factor: Desktop/Wall-Mounting |
| Unit Box Height | 0.075 |
| Unit Box Length | 0.355 |
| Unit Box Width | 0.215 |
| Model name | S3016-16GT |
Management features
| Switch layer | L2 |
| Switch type | Unmanaged |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| Networking standards | IEEE 802.3/IEEE 802.3ab/IEEE 802.3u |
Data transmission
| Forwarding rate | 23.8 Mpps |
| Jumbo frames | 12000 |
| Jumbo frames support | Yes |
| MAC address table | 16000 entries |
| Packet buffer memory | 8.4 MB |
| Switching capacity | 32 Gbit/s |
Design
| Form factor | Desktop/Wall-Mounting |
| Housing material | Metal |
| LED indicators | Yes |
| Product colour | Black |
| Rack mounting | Yes |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Input current | 0.4 A |
| Power consumption (typical) | 7.8 W |
| Power source | DC |
| Power supply included | Yes |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | No |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Depth | 119 mm |
| Height | 44 mm |
| Weight | 740 g |
| Width | 294 mm |
Packaging data
| Package depth | 215 mm |
| Package height | 75 mm |
| Package weight | 1297 g |
| Package width | 353 mm |
