The SWM282 is a high-capacity L2 managed switch with enhanced L3 capabilities, built to simplify network control while delivering power and connectivity at scale. It features 24 PoE+ ports, supplying up to 30 W per port with a total power budget of 300 W, and 4 SFP ports. With support for PROFINET and other industrial protocols, this 24-port switch is an ideal choice for enterprise networks and IIoT solutions.
General
| Unit Calculated Weight | 2.58 kg |
| Unit Calculated Volume | 0.01716 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | Teltonika SWM282. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1x, IEEE 802.3af, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.52 |
| Unit Box Width | 0.33 |
| Model name | SWM282000200 |
| Model | SWM282 |
Management features
| Quality of Service (QoS) support | Yes |
| Switch layer | L2+ |
| Switch type | Managed |
| Traffic shaping | Yes |
| Web-based management | Yes |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | AC-in jack |
| SFP module slots quantity | 4 |
Network
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x |
| Port mirroring | Yes |
| Rate limiting | Yes |
| VLAN support | Yes |
Data transmission
| Forwarding rate | 83.33 Mpps |
| Jumbo frames | 10000 |
| Jumbo frames support | Yes |
| MAC address table | 8000 entries |
| Packet buffer memory | 0.512 MB |
| Static route | Yes |
| Switching capacity | 56 Gbit/s |
Security
| Authentication type | RADIUS,TACACS+ |
| DHCP features | DHCP client/DHCP server/DHCPv6 client |
| Loop protection | Yes |
| MAC address filtering | Yes |
| Queue scheduling algorithms | SP/Weighted Round Robin (WRR)/WFQ |
Design
| Housing material | Aluminium |
| International Protection (IP) code | IP30 |
| Product colour | Black |
| Rack mounting | Yes |
| Reset button | Yes |
Performance
| Built-in processor | Yes |
| Firmware upgradeable | Yes |
| Flash memory | 16 MB |
| Internal memory | 128 MB |
| Memory type | DDR3-SDRAM |
| Processor frequency | 500 MHz |
Power
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 330 W |
| Power source | AC |
| Power supply included | No |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) modes | Alternative A |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet (PoE) type supported | Active PoE/PoE+ |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 300 W |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 50 °C |
Weight & dimensions
| Depth | 234 mm |
| Height | 44 mm |
| Weight | 2291 g |
| Width | 483 mm |
Packaging content
| Quick start guide | Yes |
Packaging data
| Package type | Box |
Certificates
| Compliance certificates | CB/CE/Federal Communications Commission (FCC)/Industry Canada (IC)/RCM/UKCA |
