A full-performance 5G (3.4 Gbps) modem for UniFi consoles and Cloud Gateways, designed for outdoor use with directional antennas, remote SIM, and dual SIM for seamless failover.
General
| Unit Calculated Weight | 2.28 kg |
| Unit Calculated Volume | 0.01175 cubm |
| Units per Shipping Box | 5 |
| Units per Pallet | 0 |
| Summary | Ubiquiti UniFi 5G Max Outdoor. Device type: Cellular network modem, Product colour: White, Housing material: Aluminium, Polycarbonate (PC). Ethernet LAN interface type: 2.5 Gigabit Ethernet. Data network: 3G, 4G, 5G, 3G standards: UMTS, 4G standard: LTE. Compliance certificates: CE, GCF, PTCRB. International Protection (IP) code: IPX6, IP67 |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.265 |
| Unit Box Width | 0.295 |
| Model name | UniFi 5G Max Outdoor |
Design
| Device type | Cellular network modem |
| Housing material | Aluminium/Polycarbonate (PC) |
| LED indicators | Yes |
| Mounting | Pole/Wall mounting |
| Product colour | White |
| Reset button | Yes |
| Suitable for outdoor use | Yes |
Ethernet LAN features
| Ethernet LAN | Yes |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
Wireless LAN features
| Wi-Fi | No |
Mobile network
| 3G standards | UMTS |
| 4G standard | LTE |
| 5G standard | Sub6 NR/Sub6 NSA/Sub6 SA |
| Data network | 3G/4G/5G |
| Number of SIM cards | 1 |
| Number of simultaneous SIM cards | 1 |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Certificates
| Compliance certificates | CE/GCF/PTCRB |
Performance
| International Protection (IP) code | IPX6, IP67 |
Power
| Power source type | PoE |
Operational conditions
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -40 - 65 °C |
Weight & dimensions
| Depth | 66.9 mm |
| Height | 220 mm |
| Weight | 1200 g |
| Width | 165 mm |
