The Switch Flex XG (USW Flex XG) is a fully managed, mult-gigabit, Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input. The USW Flex XG sports slim, compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
- (1) GbE, 802.3at PoE+ RJ45 input
- (4) 10GbE RJ45 ports
- Compact, slim housing
General
| Unit Calculated Weight | 1.59 kg |
| Unit Calculated Volume | 0.004563 cubm |
| Units per Shipping Box | 10 |
| Units per Pallet | 0 |
| Summary | Ubiquiti UniFi Switch Flex XG. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 4. Switching capacity: 82 Gbit/s. Networking standards: IEEE 802.3at. DC input voltage: 5 V. Power over Ethernet (PoE) |
| Unit Box Height | 0.075 |
| Unit Box Length | 0.285 |
| Unit Box Width | 0.175 |
| Model name | Switch Flex XG |
| Model | UBIQUITI Switch Flex XG (USW-FLEX-XG) |
Management features
| Switch layer | L2 |
| Switch type | Managed |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
Network
| 10G support | Yes |
| Ethernet LAN data rates | 10,100,1000,2500,5000,10000 Mbit/s |
| Networking standards | IEEE 802.3at |
Data transmission
| Forwarding rate | 61.012 Mpps |
| Switching capacity | 82 Gbit/s |
| Throughput | 41 Gbit/s |
Design
| Housing material | Polycarbonate (PC) |
| LED indicators | Yes |
| Product colour | White |
| Rack mounting | No |
| Reset button | Yes |
Power
| AC input voltage | 90 - 264 V |
| DC input voltage | 5 V |
| Input current | 5 A |
| Power consumption (max) | 25 W |
| Power supply included | Yes |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -5 - 45 °C |
Weight & dimensions
| Depth | 185 mm |
| Height | 32 mm |
| Weight | 1200 g |
| Width | 135 mm |
Logistics data
| Harmonized System (HS) code | 85176990 |
