All-weather, vandal-resistant 12MP PoE camera with panoramic 360° coverage, digital pan-tilt-zoom functionality, and smart IR functionality.
General
| Unit Calculated Weight | 1.34 kg |
| Unit Calculated Volume | 0.0092 cubm |
| Units per Shipping Box | 8 |
| Units per Pallet | 0 |
| Summary | Ubiquiti G6 Pro 360. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Dome. Lens viewing angle, horizontal: 180°, Lens viewing angle, vertical: 180°, Lens viewing angle, diagonal: 180°. Optical sensor size: 25.4 / 1.6 mm (1 / 1.6"). Night vision distance: 15 m, LED type: IR |
| Unit Box Height | 0.135 |
| Unit Box Length | 0.2 |
| Unit Box Width | 0.2 |
Design
| Form factor | Dome |
| Housing material | Aluminium/Polycarbonate (PC) |
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Mounting type | Ceiling/wall |
| Product colour | Black |
| Protection features | Vandal proof/Weatherproof |
| Weatherproof | Yes |
Performance
| Built-in processor | Yes |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Placement supported | Indoor & outdoor |
| Processor model | ARM Cortex-A53 |
| Type | IP security camera |
Camera
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 180 ° |
| Lens viewing angle, horizontal | 180 ° |
| Lens viewing angle, vertical | 180 ° |
Image sensor
| Optical sensor size | 1/1.6 " |
Lens system
| Number of lenses | 1 |
| Zoom capability | Yes |
Night vision
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 15 m |
Video
| Frame rate | 24 fps |
| Image quality adjustment | Brightness/Colour depth/Contrast/HDR/Sharpness |
| Maximum resolution | 3504 x 3504 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 2D noise reduction,3D noise reduction |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Total megapixels | 12 MP |
Audio
| Audio system | 2-way |
| Built-in microphone | Yes |
| Built-in speaker(s) | Yes |
| Number of microphones | 2 |
Network
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
Storage
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Intelligent Video Surveillance (IVS) system features | Human detection/Pet detection/Vehicle detection |
Management features
| Reset button | Yes |
Power
| DC output voltage | 37,42.5,48,54,57 |
| Power consumption (max) | 7.14 W |
| Power source type | PoE+ |
Operational conditions
| Operating relative humidity (H-H) | 0 - 90 % |
| Operating temperature (T-T) | -30 - 50 °C |
Weight & dimensions
| Diameter | 147 mm |
| Height | 65.5 mm |
| Weight | 610 g |
Sustainability
| Compliance certificates | CE/Federal Communications Commission (FCC)/Industry Canada (IC)/National Defense Authorization Act (NDAA) |
Packaging content
| Manual | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Screws included | Yes |
Technical details
| Night mode | Yes |
