The latest generation of Redwing power supplies combines an exciting design with modern technology and top quality. In the current revision, the power supply series has been completely revised and adapted to the demands of today's computer systems. The result not only convinces through its efficient technic, but with its modern design and high stability. The connections have been coordinated to current systems and four integrated safety circuits always ensure safe operation.
General
| Unit Calculated Weight | 1.88 kg |
| Unit Calculated Volume | 0.00451 cubm |
| Units per Shipping Box | 10 |
| Units per Pallet | 300 |
| Summary | Xilence XN053. Total power: 600 W, AC input voltage: 200 - 240 V, Max output current (+3.3V): 24 A. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 40 cm, PCI Express power cable length: 50 cm. Purpose: PC. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s) |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.225 |
| Unit Box Width | 0.165 |
Power
| AC input voltage | 200 - 240 V |
| Max output current (+12V) | 38 A |
| Max output current (+3.3V) | 24 A |
| Max output current (+5V) | 24 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.5 A |
| Power protection features | Over voltage/Overload/Short circuit/Under voltage |
| Total power | 600 W |
Ports & interfaces
| Cabling type | Non-Modular |
| Motherboard power cable length | 400 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 3 |
| PCI Express power cable length | 500 mm |
| PCI Express power connectors (6+2 pin) | 1 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
Performance
| Purpose | PC |
Design
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Product colour | Black |
