The Gaming GOLD Series is a PC power supply series with a fixed cable harness, as well as a 750W ARGB variant. The noble design with its black powder coating, the 120mm silent, black or transparent fan and the fan grille emphasizes the valuable character of this series.
The maximum voltage stability and the six integrated safety circuits ensure safe operation even in heated workflows or gaming sessions. The power supplies are suitable for the highest demands in gaming, multi-media application and streaming areas and have low power consumption during these intensive phases. The power supplies achieve the 80+ GOLD requirements.
- Whisper-quiet cooling: Large 120mm fan*
- Excellent airflow design for improved heat dissipation
- With the following safety equipment:
- OVP (overvoltage protection)
- UVP (Undervoltage Protection)
- SCP (short circuit protection)
- OLP (overload protection)
- OTP (over temperature protection)
- OCP (overcurrent protection)
- Low standby power consumption
- High energy
General
| Model name | XN320 | XP650R12 |
| Summary | Xilence Gaming Gold Series XP650R12. Total power: 650 W, AC input voltage: 200 - 240 V, Peak power: 650 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, WEEE |
| Unit Box Height | 0.205 |
| Unit Box Length | 0.265 |
| Unit Box Width | 0.1 |
Power
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 200 - 240 V |
| Combined power (+12V) | 650 W |
| Combined power (+3.3V) | 100 W |
| Combined power (+5V) | 100 W |
| Input current | 6.3 A |
| Max output current (+12V1) | 54.1 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Maximum input current (@220V) | 6.3 A |
| Peak power | 650 W |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under power |
| Total power | 650 W |
Ports & interfaces
| Cabling type | Non-Modular |
| CPU power connector (4+4 pin) | Yes |
| Motherboard power cable length | 550 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| PCI Express power connectors (6+2 pin) | 3 |
Performance
| 80 PLUS certification | 80 PLUS Gold |
| ATX version | 2.52 |
| Bearing technology | Hypro Bearing |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
Design
| Cooling type | Active |
| Fan diameter | 120 mm |
| On/off switch | Yes |
| Product colour | Black |
Certificates
| Compliance certificates | RoHS/WEEE |
Weight & dimensions
| Depth | 270 mm |
| Height | 95 mm |
| Weight | 2300 g |
| Width | 195 mm |
Technical details
| Sustainability certificates | ErP |
| Sustainability compliance | Yes |
