The compact and discreet AXIS M4216-LV delivers great images, day and night. With a deep learning processing unit (DLPU), it’s possible to take advantage of intelligent applications based on deep learning on the edge. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network. Designed to blend seamlessly into any environment, the camera can be repainted and offers a wide range of accessories for discreet monitoring. It features an HDMI port and offers the flexibility to add audio and I/O connectivity using accessories.
- Great image quality in 4 MP; HDMI output for public viewing monitors; Support for analytics with deep learning; Varifocal lens with remote zoom and focus; WDR, Lightfinder and OptimizedIR
General
| Unit Calculated Weight | 0.5 kg |
| Unit Calculated Volume | 0.001248 cubm |
| Units per Shipping Box | 1 |
| Summary | Axis 02113-001. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Minimum illumination: 0.18 lx, Tilt angle range: -40 - 65°, Pan range: -180 - 180°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Focal length range: 3 - 6 mm |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.13 |
| Unit Box Width | 0.12 |
| Model | M4216-LV |
Design
| Form factor | Dome |
| Housing material | Aluminium/Polycarbonate (PC) |
| IK code | IK08 |
| International Protection (IP) code | IP42 |
| Mounting type | Ceiling/wall |
| Product colour | White |
Performance
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Languages support | English/French/German/Italian/Japanese/Korean/Portuguese/Russian/Simplified Chinese/Spanish/Traditional Chinese |
| Number of languages | 11 |
| Placement supported | Indoor |
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Camera
| Camera pan control | Yes |
| Camera shutter speed | 1/37500 - 1/5 s |
| Camera tilt control | Yes |
| Minimum illumination | 0.18 lx |
| Pan range | -180 - 180 ° |
| Tilt angle range | -40 - 65 ° |
Image sensor
| Number of sensors | 1 |
| Optical sensor size | 1/2.7 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
Lens system
| Focal length range | 3 - 6 mm |
| Number of lenses | 1 |
| Zoom capability | Yes |
Night vision
| Infra-red wavelength | 855 nm |
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 20 m |
Video
| Flip & mirror | Yes |
| Frame rate | 30 fps |
| Maximum resolution | 2304 x 1728 pixels |
| Privacy masking | Yes |
| Supported video modes | 1080p/720p |
| Text caption overlay | Yes |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.265 |
| Video streaming | Yes |
Network
| Bluetooth | No |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1x/IEEE 802.3af/IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, HDMI, LLDP |
| Wi-Fi | No |
Storage
| Built-in HDD | No |
| Built-in SSD | No |
| Compatible memory cards | MicroSD (TransFlash)/MicroSDHC/MicroSDXC/SD |
| Flash memory | 512 MB |
| Internal memory | 1024 MB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
Security
| Active tampering alarm | Yes |
| Alert notification type | E-mail,Text alert message |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Password protection | Yes |
| Security algorithms | EAP-TLS |
| Video motion detection | Yes |
Power
| Power consumption (max) | 9.7 W |
| Power consumption (typical) | 5 W |
| Power source type | PoE |
Operational conditions
| Operating relative humidity (H-H) | 10 - 85 % |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 65 °C |
System requirements
| Windows operating systems supported | Yes |
Weight & dimensions
| Diameter | 121 mm |
| Height | 71 mm |
| Weight | 375 g |
Packaging content
| Number of cameras | 1 |
Other features
| Doesn't contain | BFR/PVC |
