TP-Link’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.
Enterprise Hardware
With Qualcomm Atheros level chipsets, high gain antennas and high
quality material, specially designed enclosure, and PoE power supply, CPE210 is
specially designed for outdoor use and can operate flawlessly in almost any climate,
with operating temperatures ranging from -40℃ (-40℉) to +70℃ (158℉).
Advanced Antenna System
Built-in High Gain Dual-Polarized Antenna
Dedicated metal reflector ensures higher gain and lower noise interference
5km+ Wireless Data Transmission
Specially designed for outdoor uses, ideal for long distance wireless data transmission over 5km+, tested in the field.
TP-Link MAXtream TDMA Technology
As network scale increases, wireless competition and collisions among CPEs and base stations will be
so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user
experience. To mitigate these effects, the CPE210 uses MAXtream TDMA Technology.
Pharos Control – Centralized Management System
CPE210 also comes equipped with centralized management software that helps users easily
manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery,
status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.
- Built-in 9dBi 2x2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 27dBm/500mw
- System-level optimizations for more than 5km long range wireless transmission
- TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
- Centralized Management System – Pharos Control
- AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes
- Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely
General
| Unit Calculated Weight | 0.745 kg |
| Unit Calculated Volume | 0.003685 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | TP-Link CPE210. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK. Power over Ethernet (PoE). Product colour: White |
| Unit Box Height | 0.105 |
| Unit Box Length | 0.27 |
| Unit Box Width | 0.13 |
| Model name | CPE210 |
Features
| 2.4 GHz | Yes |
| 5 GHz | No |
| 6 GHz | No |
| Automatic channel scanning | Yes |
| Automatic channel selection | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Frequency band | 2.4 - 2.483 GHz |
| Maximum data transfer rate | 300 Mbit/s |
| Maximum outdoor range | 5000 m |
| MIMO | Yes |
| Networking standards | IEEE 802.11b/IEEE 802.11g/IEEE 802.11n |
| VLAN support | Yes |
| Wireless isolation | Yes |
Security
| Auto Wireless Distribution System (WDS) | Yes |
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| Security algorithms | AES/TKIP/WPA/WPA2/WPA2-PSK/WPA-PSK |
| Service Set Identifier (SSID) features | SSID broadcast/SSID broadcast on/off |
Protocols
| Universal Plug and Play (UPnP) | Yes |
Management features
| Firmware upgradeable | Yes |
| Management platform | Pharos Control |
| Web-based management | Yes |
Ports & interfaces
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
Power
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Output current | 0.25 A |
| Output voltage | 24 V |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
Design
| International Protection (IP) code | IPX5 |
| LED indicators | Status |
| Placement | Pole |
| Product colour | White |
| Reset button | Yes |
Antenna
| Antenna direction type | Directional |
| Antenna gain level (max) | 9 dBi |
| Antenna type | Internal |
| Polarization | Dual polarization |
Performance
| Built-in processor | Yes |
| Flash memory | 8 MB |
| Internal memory | 64 MB |
| Processor architecture | MIPS 74Kc |
| Processor frequency | 560 MHz |
| Processor model | Qualcomm Atheros |
Certificates
| Certification | CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark CE, FCC, RoHS |
Weight & dimensions
| Depth | 79 mm |
| Height | 60 mm |
| Width | 224 mm |
Packaging data
| Package depth | 270 mm |
| Package height | 106 mm |
| Package weight | 760 g |
| Package width | 132 mm |
Packaging content
| Cables included | AC |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -30 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -40 - 70 °C |
