Long Distance Starts with External Antennas
Two detachable external antennas for 5 GHz and 2.4 GHz provide optimal coverage and greater flexibility for your network.
Ideal for High-Density Outdoor Scenes
OFDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.
Equipped with an IP67 weatherproof enclosure, our EAP625-Outdoor HD withstands the most extreme environments.
Flexible Deployment with Omada Mesh and PoE Support
- Less Wiring with Omada Mesh
- Powered with PoE+ Switch
- Powered with Passive PoE
- Up to 1.8 Gbps WiFi 6 Speeds: 574 Mbps on 2.4 GHz + 1201 Mbps on 5 GHz
- Supports WiFi 6 technologies, such as 1024-QAM, OFDMA, etc
- High-density connectivity up to 1,000+ clients
- Long-range coverage with the high-power amplifier and 2× detachable antennas
- IP67 weatherproof enclosure for various outdoor environments
- Advanced Functions: Centralized management, Omada mesh, and seamless roaming
- PoE+ Powered: Supports both 802.3at PoE (adapter not included)
General
| Unit Calculated Weight | 1.46 kg |
| Unit Calculated Volume | 0.006851 cubm |
| Units per Shipping Box | 8 |
| Units per Pallet | 0 |
| Summary | TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal. Power over Ethernet (PoE). Product colour: White |
| Unit Box Height | 0.08 |
| Unit Box Length | 0.34 |
| Unit Box Width | 0.22 |
| Model name | EAP625-OUTDOOR HD |
| Series | Omada |
Features
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Cabling technology | 10/100/1000Base-T(X) |
| Frequency band | 2.4 - 5 GHz |
| Maximum data transfer rate | 1800 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n |
| Number of users | 1020 user(s) |
Security
| IP address filtering | Yes |
| Security algorithms | WPA2-Enterprise/WPA2-Personal/WPA3-Enterprise/WPA3-Personal/WPA-Enterprise/WPA-Personal |
Power
| Power over Ethernet (PoE) | Yes |
Design
| International Protection (IP) code | IP67 |
| LED indicators | Yes |
| Placement | Pole,Wall |
| Product colour | White |
| Reset button | Yes |
Antenna
| Antenna type | External |
| Antennas quantity | 2 |
Weight & dimensions
| Depth | 182.2 mm |
| Height | 56.9 mm |
| Width | 280.4 mm |
Packaging content
| Quantity per pack | 1 pc(s) |
