TP-LINK Omada 6000 Mbps IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax Bluetooth 5.2 1x
General
| Unit Calculated Weight | 1.38 kg |
| Unit Calculated Volume | 0.0081 cubm |
| Units per Shipping Box | 6 |
| Units per Pallet | 0 |
| Summary | TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 6000 Mbit/s. Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH. Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White |
| CnCode | 85176200 |
| Unit Box Height | 0.09 |
| Unit Box Length | 0.285 |
| Unit Box Width | 0.26 |
| Model name | EAP683 UR |
| Series | Omada |
Features
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Airtime Fairness (ATF) | Yes |
| Automatic channel scanning | Yes |
| Automatic channel selection | Yes |
| Band steering | Yes |
| BeamForming | Yes |
| Ethernet LAN data rates | 10/100/1000/2500 Mbit/s |
| Fast roaming | Yes |
| Frequency band | 2.4 - 6 GHz |
| Maximum data transfer rate | 6000 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4804 Mbit/s |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3at |
| Number of users | 510 user(s) |
| Quality of Service (QoS) support | Yes |
| Rate limiting | Yes |
| VLAN support | Yes |
Security
| Access Control List (ACL) | Yes |
| MAC address filtering | Yes |
| Security algorithms | HTTPS/SNMP/SNMPv2/SNMPv3/SSH |
| Service Set Identifier (SSID) features | Multiple SSIDs |
Management features
| Firmware upgradeable | Yes |
| Syslog | Yes |
Ports & interfaces
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| DC voltage range | 12 V |
| Power over Ethernet (PoE) | Yes |
Design
| LED indicators | Yes |
| Placement | Ceiling,Wall |
| Product colour | White |
| Reset button | Yes |
Antenna
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 5 dBi |
| Antenna type | Internal |
Weight & dimensions
| Depth | 220 mm |
| Height | 32.5 mm |
| Width | 220 mm |
Packaging data
| Package type | Box |
Packaging content
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
| Quick start guide | Yes |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
