- 1/2.9 ” CMOS; 2688x1520 @ 20FPS
- Minimum illumination: 0.008 lux @ F1.5(Color,30IRE); 0.0008 lux @ F1.5(B/W,30IRE); 0 lux (Illuminator on)
- True Day/Night (ICR), BLC/ HLC/ True WDR(120dB) / 3D DNR
- 2.7 mm–13.5 mm variocal lens (104°–29°)
- Up to 40 meters IR Illumination, Smart IR
- ONVIF (Profile S/Profile T); CGI; P2P; Milestone
- SD Card slot 256 GB max, Built-in MIC
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Eyeball design, Metal case, IP67, -30°C~+60°C, PoE / 12VDC power. 6.1 W max
- Free IP monitoring software available
General
| Unit Calculated Weight | 0.895 kg |
| Unit Calculated Volume | 0.003985 cubm |
| Units per Shipping Box | 20 |
| Units per Pallet | 0 |
| Unit Box Height | 0.135 |
| Unit Box Length | 0.16 |
| Unit Box Width | 0.155 |
| Model | IPC-HDW2441T-ZS-27135 |
Design
| Form factor | Eyeball |
| International Protection (IP) code | IP67 |
| Product colour | White |
Performance
| Wide Dynamic Range (WDR) | Yes |
Camera
| Camera shutter speed | 1/3 s–1/100,000 s s |
| Minimum illumination | 0.0008 lx |
Image sensor
| Number of sensors | 1 |
| Optical sensor size | 1/2.9 " |
| Sensor type | CMOS |
Lens system
| Focal length range | 2.7–13.5 mm |
Night vision
| B/W night vision distance | 40 m |
| LED type | IR |
| Night vision | Yes |
Video
| 3D NR (Noise Reduction) | Yes |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Total megapixels | 4 MP |
Audio
| Built-in microphone | Yes |
Storage
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Power
| DC output voltage | 12 |
| Power consumption (typical) | 6.1 W |
| Power source type | DC,PoE |
Operational conditions
| Operating temperature (T-T) | -30°C~+60°C °C |
Weight & dimensions
| Diameter | 122 mm |
| Height | 108.3 mm |
| Weight | 690 g |
