> 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688 × 1520 (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Supports max. 256 G Micro SD card; built in MIC.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD Plus.
General
| Unit Calculated Weight | 0.85 kg |
| Unit Calculated Volume | 0.003123 cubm |
| Units per Shipping Box | 1 |
| Unit Box Height | 0.13 |
| Unit Box Length | 0.155 |
| Unit Box Width | 0.155 |
| Model | IPC-HDW2541T-ZS-27135-S2 |
Design
| Form factor | Eyeball |
| International Protection (IP) code | IP67 |
| Product colour | White |
Performance
| Connectivity technology | Wired |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
Camera
| Camera shutter speed | 1/3 s–1/100,000 s |
Image sensor
| Number of sensors | 1 |
| Optical sensor size | 1/2.7 " |
| Sensor type | CMOS |
Night vision
| B/W night vision distance | 40 m |
| LED type | IR |
| Night vision | Yes |
Video
| 3D NR (Noise Reduction) | Yes |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Maximum resolution | 2960 × 1668 pixels |
| Total megapixels | 5 MP |
Audio
| Built-in microphone | Yes |
Storage
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Power
| DC output voltage | 12 |
| Power consumption (typical) | 3 W |
| Power source type | DC,PoE |
Operational conditions
| Operating temperature (T-T) | –30 °C to +60 °C °C |
| Storage temperature (T-T) | –30 °C to +60 °C °C |
Weight & dimensions
| Diameter | 122 mm |
| Height | 108.3 mm |
| Weight | 680 g |
Technical details
| Lens mount interface | M14 |
