Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.
Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability./
The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.
Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.
Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
General
| Unit Calculated Weight | 0.4 kg |
| Unit Calculated Volume | 0.001666 cubm |
| Units per Shipping Box | 20 |
| Units per Pallet | 0 |
| Long Description | Ubiquiti NanoStation 5AC Loco. 5 GHz, Maximum data transfer rate: 1000 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White |
| Summary | Ubiquiti NanoStation 5AC Loco. 5 GHz, Maximum data transfer rate: 1000 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White |
| Unit Box Height | 0.115 |
| Unit Box Length | 0.2 |
| Unit Box Width | 0.06 |
| Model name | NanoStation 5AC Loco |
| Model | UBIQUITI airMAX NanoStation 5AC Loco |
Features
| 5 GHz | Yes |
| Ethernet LAN data rates | 10/100/1000 Mbit/s |
| Frequency band | 5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz |
| Maximum data transfer rate | 1000 Mbit/s |
| Maximum outdoor range | 10000 m |
| Modulation | 16-QAM/256-QAM/64-QAM/BPSK/QPSK |
| Throughput data rate | 450 Mbit/s |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Power
| AC input voltage | 24 V |
| Input current | 0.5 A |
| Power over Ethernet (PoE) | Yes |
Design
| LED indicators | Network/Power/Signal strength |
| Placement | Ceiling |
| Product colour | White |
Antenna
| Antenna type | Internal |
Performance
| Built-in processor | Yes |
| Internal memory | 64 MB |
| Operating system installed | AirOS |
Certificates
| Certification | CE, FCC, IC |
Weight & dimensions
| Depth | 77.5 mm |
| Height | 59.1 mm |
| Weight | 180 g |
| Width | 179 mm |
Operational conditions
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -40 - 70 °C |
Logistics data
| Harmonized System (HS) code | 85176990 |
