All-weather WiFi 7 AP with 4 spatial streams, an integrated directional super antenna, and versatile mounting options.
- WiFi 7
- 4 spatial streams
- 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
- Software-adjustable antenna beamwidth for balanced coverage with the included omni antennas
- 200+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
- Versatile wall and pole mounting
- Weatherproof (outdoor exposed)
General
| Unit Calculated Weight | 1.92 kg |
| Unit Calculated Volume | 0.008457 cubm |
| Units per Shipping Box | 6 |
| Units per Pallet | 0 |
| Summary | Ubiquiti U7 Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 4300 Mbit/s. Security algorithms: PPSK, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3. Ethernet LAN data rates: 2500 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 19 W |
| Unit Box Height | 0.23 |
| Unit Box Length | 0.27 |
| Unit Box Width | 0.1 |
| Model name | U7 Outdoor |
| Model | U7-Outdoor |
Features
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Ethernet LAN data rates | 2500 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Maximum data transfer rate | 4300 Mbit/s |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11be/IEEE 802.11g/IEEE 802.11n/IEEE 802.1Q/IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Rate limiting | Yes |
| Spatial streams | 4 |
| Throughput data rate | 4324 Mbit/s |
| VLAN support | Yes |
Security
| Security algorithms | PPSK/WPA/WPA2/WPA3/WPA-Enterprise/WPA-PSK |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Power
| DC voltage range | 44 - 57 V |
| Power consumption (max) | 19 W |
| Power over Ethernet (PoE) | Yes |
Design
| Housing material | Aluminium,Polycarbonate (PC) |
| International Protection (IP) code | IPX6 |
| LED indicators | Yes |
| Placement | Ceiling,Pole,Wall |
| Product colour | White |
| Recommended usage | Outdoor |
| Reset button | Yes |
Antenna
| Antenna connector type | RP-SMA |
| Antenna direction type | Omni-directional |
| Antenna features | Detachable antenna |
| Antenna gain level (max) | 12.5 dBi |
| Antenna type | External |
| Antennas quantity | 2 |
| Number of connectors | 2 |
Certificates
| Compliance certificates | CE/Federal Communications Commission (FCC)/Industry Canada (IC) |
Weight & dimensions
| Depth | 54.5 mm |
| Height | 208 mm |
| Weight | 1200 g |
| Width | 170 mm |
Packaging content
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
Operational conditions
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -30 - 60 °C |
Sustainability
| Sustainability compliance | Yes |
