Compact, all-weather camera with ultra-low latency pan-tilt-zoom control and versatile mounting options./
Compact, all-weather camera with ultra-low latency pan-tilt-zoom control and versatile mounting options.
General
| Unit Calculated Weight | 1.13 kg |
| Unit Calculated Volume | 0.00701 cubm |
| Units per Shipping Box | 8 |
| Long Description | Ubiquiti G5 PTZ. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Wall/Pole, Product colour: White, Form factor: Dome. Lens viewing angle, horizontal: 99.7°, Lens viewing angle, vertical: 51.9°, Lens viewing angle, diagonal: 121°. Sensor type: CMOS, Optical sensor size: 50.8 / 7 mm (2 / 7"). Focal length range: 3.42–6.85 |
| Summary | Ubiquiti G5 PTZ. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Wall/Pole, Product colour: White, Form factor: Dome. Lens viewing angle, horizontal: 99.7°, Lens viewing angle, vertical: 51.9°, Lens viewing angle, diagonal: 121°. Sensor type: CMOS, Optical sensor size: 50.8 / 7 mm (2 / 7"). Focal length range: 3.42–6.85 |
| Unit Box Height | 0.115 |
| Unit Box Length | 0.26 |
| Unit Box Width | 0.14 |
| Model | G5-PTZ |
Design
| Form factor | Dome |
| IK code | IK04 |
| International Protection (IP) code | IP66 |
| Mounting type | Wall/Pole |
| Product colour | White |
| Weatherproof | Yes |
Performance
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| PTZ control | Yes |
| Type | IP security camera |
Camera
| Lens viewing angle, diagonal | 121° ° |
| Lens viewing angle, horizontal | 99.7 ° |
| Lens viewing angle, vertical | 51.9 ° |
Image sensor
| Number of sensors | 1 |
| Optical sensor size | 2/7 " |
| Sensor type | CMOS |
Lens system
| Focal length range | 3.42-6.85 mm |
| Maximum aperture number | 2.4 |
| Minimum aperture number | 1.85 |
Night vision
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 20 m |
Video
| Maximum resolution | 2688 x 1512 pixels |
| Total megapixels | 4 MP |
Audio
| Built-in microphone | Yes |
Network
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
Storage
| Built-in HDD | No |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
Power
| DC output voltage | 37,57 |
| Power source type | DC,PoE |
Operational conditions
| Operating relative humidity (H-H) | 0 - 90 % |
| Operating temperature (T-T) | -30 - 45 °C |
Weight & dimensions
| Diameter | 152.5 mm |
| Height | 90 mm |
| Weight | 580 g |
Packaging content
| Mounting kit | Yes |
| Number of cameras | 1 |
