The Neomounts WL40-550BL18 LEVEL is a full motion wall mount for flat screens up to 75" with a maximum weight capacity of 45 kg. The versatile tilt (18°) and swivel (54°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation.
The LEVEL-550 wall mount has a depth of 5,5-71 cm and is suitable for screens that meet VESA hole pattern 200x100 to 800x400 mm.
The WL40-550BL18 features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. The mount is equipped with cable management, to secure any loose cables on the back of the screen.
General
| Unit Calculated Weight | 12.4 kg |
| Unit Calculated Volume | 0.02354 cubm |
| Units per Shipping Box | 2 |
| Units per Pallet | 0 |
| Summary | Neomounts WL40-550BL18 TV mount wall 43-75" - full motion - easy install. Maximum weight capacity: 45 kg, Minimum screen size: 109.2 cm (43"), Maximum screen size: 190.5 cm (75"), Minimum VESA mount: 200 x 100 mm, Maximum VESA mount: 800 x 400 mm. Tilt angle range: -3 - 15°, Swivel angle range: 0 - 54°, Angle of rotation: 6°, Distance to the wall (min): 5.5 cm, Distance to the wall (max): 71 cm. Product colour: Black |
| Unit Box Height | 0.34 |
| Unit Box Length | 0.895 |
| Unit Box Width | 0.065 |
Mounting
| Maximum screen size | 75 " |
| Maximum VESA mount | 800 x 400 mm |
| Maximum weight capacity | 45 kg |
| Maximum weight capacity (per display) | 45 kg |
| Minimum screen size | 43 " |
| Minimum VESA mount | 200 x 100 mm |
| Mounting type | Wall |
| Number of displays supported | 1 |
| Panel mounting interface | 200 x 100/200 x 150/200 x 200/200 x 300/200 x 400/300 x 200/300 x 300/350 x 350/400 x 200/400 x 300/400 x 400/440 x 400/500 x 400/600 x 200/600 x 300/600 x 400/680 x 300/800 x 200/800 x 400 mm |
Ergonomics
| Angle of rotation | 6 ° |
| Cable management | Yes |
| Distance to the wall (max) | 710 mm |
| Distance to the wall (min) | 55 mm |
| Height adjustment | No |
| Pivot angle | -3 - 3 ° |
| Rotating | Yes |
| Swivel angle | 54 ° |
| Swivel angle range | 0 - 54 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -3 - 15 ° |
| Type | Full motion |
Design
| Housing material | Steel |
| Product colour | Black |
Technical details
| Country of origin | China |
| Lockable | Not lockable |
| Package net weight | 11700 g |
| Quantity per pack | 1 pc(s) |
Packaging content
| Mounting kit | Yes |
Weight & dimensions
| Depth | 55 mm |
| Depth (max) | 55 mm |
| Height | 436 mm |
| Weight | 9900 g |
| Width | 850 mm |
Packaging data
| Package depth | 340 mm |
| Package height | 65 mm |
| Package weight | 11700 g |
| Package width | 882 mm |
Logistics data
| Harmonized System (HS) code | 7326909890 |
| Master (outer) case gross weight | 24000 g |
| Master (outer) case height | 360 mm |
| Master (outer) case length | 145 mm |
| Master (outer) case net weight | 22100 g |
| Master (outer) case width | 902 mm |
| Products per master (outer) case | 2 pc(s) |
| Products per pallet (EU) | 40 pc(s) |
