The Neomounts WL40S-850BL14 LEVEL is a full motion wall mount for flat screens up to 65" with a maximum weight capacity of 40 kg. The versatile tilt (14°) and swivel (45°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation.
The LEVEL-850 wall mount has a depth of 4,7-55,5 cm and is suitable for screens that meet VESA hole pattern 100x100 to 400x400mm.
The WL40S-850BL14 features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. A separate spirit level tool is included with the wall mount, as well as a fixing template, to ensure easy installation of the mount. The mount is equipped with high quality steel cable management, to secure any loose cables at the back of the screen.
General
| Unit Calculated Weight | 7.1 kg |
| Unit Calculated Volume | 0.01226 cubm |
| Units per Shipping Box | 1 |
| Summary | Neomounts WL40S-850BL14 TV mount wall 40-65" - full motion - fast installation. Maximum weight capacity: 40 kg, Minimum screen size: 101.6 cm (40"), Maximum screen size: 165.1 cm (65"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 400 x 400 mm. Tilt angle range: -2 - 12°, Swivel angle range: 0 - 45°, Angle of rotation: 6°, Distance to the wall (min): 4.7 cm, Distance to the wall (max): 55.5 cm. Product colour: Black |
| Unit Box Height | 0.34 |
| Unit Box Length | 0.515 |
| Unit Box Width | 0.07 |
Mounting
| Maximum screen size | 65 " |
| Maximum VESA mount | 400 x 400 mm |
| Maximum weight capacity | 40 kg |
| Maximum weight capacity (per display) | 40 kg |
| Minimum screen size | 40 " |
| Minimum VESA mount | 100 x 100 mm |
| Mounting type | Wall |
| Number of displays supported | 1 |
| Panel mounting interface | 100 x 100/100 x 150/100 x 200/200 x 100/200 x 200/200 x 300/200 x 400/300 x 200/300 x 300/400 x 200/400 x 300/400 x 400 mm |
Ergonomics
| Angle of rotation | 6 ° |
| Cable management | Yes |
| Distance to the wall (max) | 555 mm |
| Distance to the wall (min) | 47 mm |
| Height adjustment | No |
| Pivot angle | -3 - 3 ° |
| Rotating | Yes |
| Swivel angle | 45 ° |
| Swivel angle range | 0 - 45 ° |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -2 - 12 ° |
| Type | Full motion |
Design
| Housing material | Steel |
| Product colour | Black |
Technical details
| Country of origin | China |
| Lockable | Not lockable |
| Package net weight | 7000 g |
| Quantity per pack | 1 pc(s) |
Packaging content
| Hex key included | Yes |
| Mounting kit | Yes |
| Number of wrenches included | 1 |
Weight & dimensions
| Depth | 47 mm |
| Depth (max) | 47 mm |
| Height | 449 mm |
| Weight | 5900 g |
| Width | 449 mm |
Packaging data
| Package depth | 342 mm |
| Package height | 62 mm |
| Package weight | 7000 g |
| Package width | 503 mm |
Logistics data
| Harmonized System (HS) code | 7326909890 |
| Master (outer) case gross weight | 21400 g |
| Master (outer) case height | 362 mm |
| Master (outer) case length | 204 mm |
| Master (outer) case net weight | 18300 g |
| Master (outer) case width | 523 mm |
| Products per master (outer) case | 3 pc(s) |
| Products per pallet (EU) | 84 pc(s) |
