RUT260 is a Teltonika Networks LTE Cat 6 cellular router with WAN failover. Balancing the key features of the RUT240 and RUT360, this cellular router is powerful, lightweight, and supports a wide variety of industrial protocols, including MQTT, SNMP, Modbus, and more.
General
| Unit Calculated Weight | 0.42 kg |
| Unit Calculated Volume | 0.001865 cubm |
| Units per Shipping Box | 1 |
| Units per Pallet | 0 |
| Summary | Teltonika RUT260. Device type: Cellular network router, Product colour: Black, Blue, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3af,.... Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), WLAN data transfer rates supported: 300 Mbit/s. Data network: 3G, LTE, SIM card type: MiniSIM, Data transfer rate (LTE) (download): 300 Mbit/s. Security algorithms: AES-CCMP, TKIP, WEP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE |
| Unit Box Height | 0.072 |
| Unit Box Length | 0.148 |
| Unit Box Width | 0.175 |
Design
| Built-in display | No |
| Device type | Cellular network router |
| Housing material | Aluminium/Plastic |
| LED indicators | LAN/Network/Power/Signal strength/WAN |
| Market positioning | Industrial |
| Mounting | DIN-rail/Wall mounting |
| Product colour | Black/Blue |
| Suitable for indoor use | Yes |
Ethernet LAN features
| DHCP client | Yes |
| DHCP server | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
| Full duplex | Yes |
| Networking standards | IEEE 802.11b/IEEE 802.11e/IEEE 802.11g/IEEE 802.11n/IEEE 802.11r/IEEE 802.3/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3bt/IEEE 802.3u |
Wireless LAN features
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported | 300 Mbit/s |
Mobile network
| Data network | 3G/LTE |
| Data transfer rate (LTE) (download) | 300 Mbit/s |
| Data transfer rate (LTE) (upload) | 50 Mbit/s |
| Number of SIM cards | 1 |
| Short Message Service (SMS) | Yes |
| SIM card type | MiniSIM |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | No |
Security
| DMZ support | Yes |
| Firewall | Yes |
| IP address filtering | Yes |
| Network address translation (NAT) | Yes |
| Security algorithms | AES-CCMP/TKIP/WEP/WPA2-Enterprise-PEAP/WPA2-PSK/WPA3-EAP/WPA3-SAE |
GPS Performance
| Assisted GPS (A-GPS) | No |
| BeiDou | No |
| Electronic compass | No |
| Embedded GNSS | No |
| Galileo | No |
| GLONASS | No |
| Quasi-Zenith Satellite System (QZSS) | No |
Performance
| Antenna connector type | SMA/RP-SMA |
| Antenna type | External |
| Antennas quantity | 3 |
| Built-in processor | Yes |
| Detachable antenna(s) | Yes |
| GPS (satellite) | No |
| Internal storage capacity | 0.016 GB |
| Operating system installed | RutOS |
| Processor frequency | 0.58 GHz |
| Processor manufacturer | Mediatek |
| RAM capacity | 0.128 GB |
| Web-based management | Yes |
Power
| Built-in battery | No |
| Power source type | DC |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -40 - 75 °C |
Weight & dimensions
| Depth | 74 mm |
| Height | 25 mm |
| Weight | 130 g |
| Width | 83 mm |
