The RUT361 is a robust cellular router with speeds of up to 300 Mbps with carrier aggregation, vital for IoT solutions demanding uninterrupted networks in challenging environments. Remote monitoring, advanced security features, and WAN failover make this LTE Cat 6 router feature-rich, and two Wi-Fi antennas ensure greater device applicability in diverse M2M applications.
- 4G LTE CAT 6
- Cellular speeds of up to 300Mbps with carrier aggregation
- WI-FI
- 802.11 b/g/n wireless access point with hotspot functionality
- WAN FAILOVER
- Automatic switching to available backup connection
- RMS
- For remote management, access & VPN services
General
| Unit Calculated Weight | 0.744 kg |
| Unit Calculated Volume | 0.004736 cubm |
| Units per Shipping Box | 5 |
| Units per Pallet | 0 |
| Summary | Teltonika Industrial 4G LTE router RUT361 Cat 6 LTE, WiFi 4, 2x RJ45 100Mb/s, IP30. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11s,.... Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), WLAN data transfer rates supported: 300 Mbit/s, Wi-Fi frequency: 2.4 GHz. Data network: 3G, LTE, SIM card type: MiniSIM, Data transfer rate (LTE) (download): 300 Mbit/s. Security algorithms: AES-CCMP, OWE, TKIP, WPA-PSK, WPA2-EAP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE, VPN support: OpenVPN IPsec GRE PPTP, L2TP |
| Unit Box Height | 0.06 |
| Unit Box Length | 0.36 |
| Unit Box Width | 0.18 |
| Model | RUT361100000 |
Design
| Built-in display | No |
| Device type | Cellular network router |
| Housing material | Aluminium |
| LED indicators | LAN/Power/Signal strength/Status |
| Product colour | Black |
| Reset button | Yes |
| Suitable for indoor use | Yes |
| Suitable for outdoor use | No |
Ethernet LAN features
| Auto MDI/MDI-X | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
| Full duplex | Yes |
| Networking standards | IEEE 802.11b/IEEE 802.11e/IEEE 802.11g/IEEE 802.11k/IEEE 802.11n/IEEE 802.11r/IEEE 802.11s/IEEE 802.11v/IEEE 802.3/IEEE 802.3az/IEEE 802.3u |
Wireless LAN features
| Wi-Fi | Yes |
| Wi-Fi frequency | 2.4 GHz |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported | 300 Mbit/s |
Mobile network
| Data network | 3G/LTE |
| Data transfer rate (LTE) (download) | 300 Mbit/s |
| Data transfer rate (LTE) (upload) | 50 Mbit/s |
| Number of SIM cards | 1 |
| Short Message Service (SMS) | Yes |
| SIM card type | MiniSIM |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
Security
| DMZ support | Yes |
| IP address filtering | Yes |
| Network address translation (NAT) | Yes |
| Security algorithms | AES-CCMP/OWE/TKIP/WPA2-EAP/WPA2-Enterprise-PEAP/WPA2-PSK/WPA3-EAP/WPA3-SAE/WPA-PSK |
| VPN support | OpenVPN IPsec GRE PPTP, L2TP |
Certificates
| Certification | CE, UKCA, RCM, UCRF, EAC, WEEE, CB |
Performance
| Antenna type | External |
| Antennas quantity | 4 |
| Internal storage capacity | 0.016 GB |
| Operating system installed | RutOS |
| Processor frequency | 0.58 GHz |
| Processor manufacturer | Mediatek |
| RAM capacity | 0.128 GB |
| RAM type | DDR2 |
| Web-based management | Yes |
Management features
| Management platform | RMS |
Power
| External power adapter | Yes |
| Input voltage | 9 - 30 V |
| Power source type | DC |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -40 - 75 °C |
