The RUT901 cellular router delivers the top-rated features of its predecessors, the RUT950 and RUT951, to the market. The device ensures high-performance, providing automatic WAN failover to an available backup connection, guaranteeing network continuity and eliminating downtime.
- Router RUT901
- 9 W PSU
- 2x Mobile antennas (swivel, SMA male)
- 2x Wi-Fi antennas (swivel, RP-SMA male)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
General
| Unit Calculated Weight | 0.82 kg |
| Unit Calculated Volume | 0.004555 cubm |
| Units per Shipping Box | 5 |
| Units per Pallet | 0 |
| Summary | Teltonika RUT901. Device type: Cellular network router, Product colour: Black, Housing material: Aluminium. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3u. Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n). Data network: 3G, 4G, LTE, 4G standard: LTE. Security algorithms: AES-CCMP, SNMPv2, SNMPv3, SSID, TKIP, WPA-PSK, WPA2-EAP, WPA2-PSK, WPA3-EAP, WPA3-SAE, VPN support: DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC... |
| Unit Box Height | 0.06 |
| Unit Box Length | 0.355 |
| Unit Box Width | 0.175 |
| Model name | RUT901000000 |
Design
| Device type | Cellular network router |
| Housing material | Aluminium |
| Product colour | Black |
| Reset button | Yes |
Ethernet LAN features
| Auto MDI/MDI-X | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
| Networking standards | IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.11r/IEEE 802.3/IEEE 802.3u |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
Wireless LAN features
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b/802.11g/Wi-Fi 4 (802.11n) |
Mobile network
| 4G standard | LTE |
| Data network | 3G/4G/LTE |
| Number of SIM cards | 2 |
| Short Message Service (SMS) | Yes |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 4 |
Security
| DMZ support | Yes |
| Firewall | Yes |
| Network address translation (NAT) | Yes |
| Security algorithms | AES-CCMP/SNMPv2/SNMPv3/SSID/TKIP/WPA2-EAP/WPA2-PSK/WPA3-EAP/WPA3-SAE/WPA-PSK |
| VPN support | DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES |
Certificates
| Compliance certificates | CB/CE/EAC/UKCA |
Performance
| Antenna connector type | SMA/RP-SMA |
| Antenna type | External |
| Antennas quantity | 4 |
| Built-in processor | Yes |
| Operating system installed | RutOS |
| Processor frequency | 0.58 GHz |
| Processor manufacturer | Mediatek |
| RAM capacity | 0.128 GB |
| RAM type | DDR2 |
Power
| Power source type | DC |
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | -40 - 75 °C |
Weight & dimensions
| Depth | 100 mm |
| Height | 50 mm |
| Weight | 297 g |
| Width | 110 mm |
Packaging data
| User guide | Yes |
